SHANGERS / CUSTOM MANUFACTURING SHOWCASE
More features. One compact part.
This non-standard machined sample combines an external thread, a hexagonal base, radial holes and an axial opening. It showcases a type of multi-feature metal part that can be developed to a customer's own drawing.
Threaded sample / overall geometry
A multi-feature machining sample
The upright photograph shows the external thread above the hexagonal base, with a stepped cylindrical section extending from it. Radial holes appear between the raised circular features. The angled view reveals the axial opening. Together, the images give a clear picture of the visible geometry without replacing the actual product with a diagram.
Custom work beyond a simple round profile
This is an example of the kinds of combined features customers may request in a machined component: threads, circular steps, openings and non-round external surfaces. Similar custom parts can be reviewed with a different profile, hole pattern or thread requirement. The manufacturing route is selected for the proposed design; this gallery does not prescribe a single process sequence for every version.
Upright view / thread and radial holes
From reference sample to a new project
A reference like this can help explain the general style of component you need. It does not limit your enquiry to the exact photographed shape. Share the drawing for your own part, or send a sample for a feasibility discussion. SHANGERS can review the requested features, material and surface-treatment requirements before confirming a custom production proposal.
End view / axial opening
A reference for your next machined part
The visible thread, radial openings and stepped body make this sample relevant to enquiries involving several machining features in one component. The thread specification, material and finish for your project are agreed from your requirements. Send the part drawing or reference sample and the required quantity to begin a custom-machining discussion.
Have a similar multi-feature part?
Send your part drawing or reference sample and the quantity you need. We will review your custom manufacturing enquiry.
